| Production Capacity(T/D): | |
|---|---|
| Width of Screen Hole(mm): | |
| Quantity: | |
Customized
jurui
The Vibrating Screen is a key equipment used for coarse pulp screening and purification in the paper making pulping process. It separates the pulp from impurities through high-frequency vibration and features high efficiency, stability and easy maintenance. Its core function is to remove knots, films, plastic particles and other coarse impurities in the pulp, improve the quality of the pulp, and is widely used in the pretreatment process of raw materials such as wood pulp, grass pulp and waste paper pulp.
| Technical parameters | ||||||
| Type | ZSK1 | ZSK2 | ZSK3 | ZSK4 | ||
| Screen area(m³) | 1 | 2 | 3 | 4 | ||
| Production capacity(t/d) | 1-30 | 4-30 | 6-45 | 8-80 | ||
| Width of screen hole(mm) | Φ3-Φ8 | |||||
| Width of screen slot(mm) | 0.5-2 | |||||
| Consistency of in flow pulp(%) | Hole screen 1-1.5 | Slot hole 0.5-0.8 | ||||
| Motor power(kw) | 3 | 4 | 5.5 | |||
